    BaoFeng UV-9Rplus IP67 Waterproof Walkie Talkies VHF/UHF Dual Band Two-Way Radios

    Stadium /Office /Highway/ Railway /Scenic/ Pier /Island/ Offshore / Urban/ road /Supermarket /Metro/ Rural /Suburban/ Hospital/ Campus /Mine /Oilfield /Tunnel
    • mode:
    • Product Category:Handheld Radio
    • Power supply:
    • Frequency:VHF 136-174mhzUHF 400-470MhzVHF136-174Mhz&UHF400-520Mhz
    • Products Details
    • Company Profile
    • Introduction
    • Mainfeature
    • Application&scenarios
    • Specification
    • Parts/Warranty

    BaoFeng UV9R Plus Waterproof UHF Walkie Talkie Dual Band Handheld Two Way Radio

    Product Description

    Features:

    *100% brand new and high quality

    *Made of high quality material, durable and practical to use

    *IP67 waterproof and dustproof (do not dive).

    *Relay forwarding confirmation (1750hz).

    *Dual frequency, dual display, dual standby.

    *High and low power switching.

    *Power saving, wideband / narrowband selection.

    *Automatic reversing light and dual-frequency standby, timeout timer (TOT).

    *50 CTCSS and 104 DCS codes.

    *Voice prompt & ANI code PC or manual program & DTMF code & PTT-ID & ATUO keyboard lock.

    *Busy channel lock function.

    *Low battery alarm, urgent alarm, and Priory scanning function.

    *U/V cross belt double table.



    Mainfeature

    Specifications:

    *Frequency range: VHF 136-174, UHF 400-520MHz

    *Theoretical communication distance: 10 km

    *Power: 8 w

    *Battery: Polymer Lithium Battery

    *Battery: 4000 mAh

    *Weight: 0.5 kg(Approx.)

    *Size: 12 * 6 * 4 cm(Approx.)

    *Specifications: US regulations

    Application&scenarios

    Specification

    General

    Frequency Range

    VHF:136-174MHz UHF400-520MHz

    Channel Capacity

    128

    Channel Spacing

    25KHz/12.5KHz

    Antenna Impedance

    50Omega

    Microphone Impedance

    600Omega

    Operating Voltage

    7.4V DCplusmn15%

    Frequency Stability

    plusmn2.5ppm

    Battery

    4500mAh (Polymer Li-ion)

    Compatible With American Military Standard(Mil-STD-810C/D/E)

    Transmitter(EIA-RS 316B STANDARD)

    RF Power Output

    10W

    Modulation Type

    FM Radio (65.0MHz-108.0MHz)

    Modulation Sensitivity

    <15microV

    Modulation Distortion

    le3%

    Max Freq Deviation

    <5KHz

    Occupied Bandwidth

    le16KHz

    Modulation Feature

    plusmn3dB

    Spurious Radiation

    le7.5muW

    Adjacent Channel Power

    le-65dB

    Receiver

    Sensitivity(12db SINAD)

    le0.15mu(12dB S/N)

    Squelch Sensitivity

    le0.1muV

    Audio Power output

    1W/16Omega

    Audio Respond

    -6

    Operation Bandwidth

    >5KHz

    Co-channel Rejection

    ge-8dB

    Blocking

    ge85dB

    Adjacent Channel Selectivity

    ge65dB

    Standby Current

    60mA,15mA

    Spurious Rejection

    ge60dB

    Intermodulation Resistance

    ge60dB

    Parts/Warranty

    Package Included:

    1*Way Radio

    1* Antenna

    1* Desktop Charger

    1*User Manual

    1* earphone

    1* clip
