1710-2690MHz DCS,3G,WIFI,LTE,4G Directional 16dBi Yagi Antenna

Stadium /Office /Highway/ Railway /Scenic/ Pier /Island/ Offshore / Urban/ road /Supermarket /Metro/ Rural /Suburban/ Hospital/ Campus /Mine /Oilfield /Tunnel
• mode:KT-1727-16
• Product Category:Antenna
• Power supply:
• Frequency:
  • Products Details
  • Company Profile
  • Introduction
  • Mainfeature
  • Application&scenarios
  • Specification
  • Parts/Warranty

1710-2690MHz Directional Yaqi Antenna

●DCS,3G,WIFI,LTE,4G system

●Point-to-pointpoint-to-multipoint system

●Wireless bridgingclient termination antenna

Mainfeature

Feature

● High gain

● Aluminum alloy framework

● Full day working

● Optimized dimension

Application&scenarios

Specification

KT-1727-16

Electrical Specifications

Frequency rangeMHz

1710-2690

BandwidthMHz

980

GaindBi

16

element

15

Half-power beam width°

H35 V30

Front-to-back ratiodB

≥16

VSWR

≤2.0

Input ImpedanceΩ

50

Polarization

Horizontal or Vertical

Maximum input powerW

100

Lightning protection

DC Ground

Input connector type

N female or others

Mechanical Specifications

Dimensions(mm)

610*84*44

Cable lengthm

1

Antenna weightkg

0.36

Operating temperature°c

-4060

Rated Wind Velocitym/s

60

Clamp

U-shape

Mounting hardwaremm

Φ35Φ50

Parts/Warranty
